Product Introduction
H Beam is a high-strength structural profile designed for load-bearing applications in construction, industrial framing, and mechanical equipment manufacturing. Characterized by its distinctive H-shaped cross-section, this product offers excellent bending resistance and structural stability, making it a core component in building beams, support frames, and mechanical bases. Available in a wide range of lengths including 5900mm, 4900mm, 4500mm, 3900mm, 3600mm, 3300mm, 2900mm, 2650mm, 2450mm, 2000mm, and 1800mm, with a fixed height of 200mm and width of 80mm, it meets diverse project requirements. With a weight of 5.2kg per linear meter, H Beam balances lightweight handling and heavy load capacity, serving as a cost-effective solution for structural engineering projects.
Product Advantage
The H-shaped cross-section of H Beam distributes stress evenly across the profile, delivering exceptional load-bearing capacity and bending resistance. It can withstand high vertical and lateral pressures, making it suitable for high-rise building columns, bridge trusses, and industrial workshop frames.
Manufactured with advanced rolling technology, H Beam features precise dimensional tolerances and consistent mechanical properties. The head height of 40mm and head width of 80mm ensure a tight fit with other structural components, reducing installation gaps and improving overall structural stability.
With a lightweight design and high strength-to-weight ratio, H Beam reduces material usage and transportation costs while maintaining structural performance. It is made from high-quality steel that can be recycled and reused, aligning with sustainable construction and manufacturing standards.
Technical Parameters
H Beam has a standardized cross-sectional structure with a height of 200mm and a width of 80mm. The head height is 40mm, ensuring optimal stress distribution in load-bearing scenarios. The product’s length options range from 1800mm to 5900mm, covering both small-scale framing and large-scale construction needs. Weighing 5.2kg per linear meter, it is easy to transport and install without compromising strength. The material undergoes strict quality control, including tensile and bending tests, to ensure compliance with international structural steel standards. Its surface is treated to resist rust and corrosion, extending service life in indoor and outdoor environments.
Model NO. | 1220*2440 |
Plywood Type | 13-Ply |
Specifications | 1220*2440*18mm |
Grade | Excellent Grade |
Transport Package | Export Standard Pallets Packing |
Bonding Strength | Ⅲ(Nc) |
Formaldehyde Emission Standards | E0 |
Place of Origins | Linyi China |
Usage | Indoor |
Specification | 1220x2440 |
FAQ
H Beam has a wider flange width than I-beams, providing better lateral stability and load-bearing capacity. Its symmetrical cross-section ensures uniform stress distribution, reducing the risk of deformation under heavy loads, making it more suitable for large-span structures.
Yes. The standard H Beam has a basic anti-corrosion surface treatment, but for highly corrosive environments such as coastal areas or chemical plants, additional galvanizing or painting treatments are recommended to enhance corrosion resistance.
The length of H Beam should be determined based on the span of the structure and load requirements. For small-span frames (within 3m), shorter lengths like 1800mm or 2000mm are sufficient, while large-span bridges or workshop frames may require lengths of 4500mm to 5900mm. It is recommended to consult structural engineers for professional calculations.
Absolutely. H Beam can be easily cut, drilled, and welded to fit specific project designs. Its uniform cross-section ensures consistent connection with bolts, welding, and other fastening methods, improving installation efficiency and structural integrity.
